| Product Code | APC series |
|---|---|
| BrandName | Hongtek |
| Country of Origin | China |
| Keywords | absolute pleated filter, absolute PP pleated cartridges, absolute pleated filter cartridges, PP Pleated Filter Cartridges, PP Pleated Filters, PP Pleated Cartridges, Pleated PP Filters, Pleated PP Cartridges, Pleated Filter Cartridges, PP Water Filter Cartridges, PP Water Filters, PP Water Cartridges, Pleated water element, Pleated filter element, Pleated water filter element, Pleated cartridge filters, Pleated cartridges china, Pleated water filter, Pleated water filter cartridges |
| Price | USD 4.96 Piece |
| Min. Order | 2 Piece |
| Payment Terms | L/C,T/T |
| Send Inquiry | |
Description
Absolute PP pleated filters are constructed with 100% advanced polypropylene materials and assembled by high technology thermal bonding equipment. Absolute PP pleated cartridges are offered in absolute rate Beta 5000(to ) retention efficiencies. Absolute pleated filter cartridges are wide chemical compatibility using 100% polypropylene materials comply with FDA, an ideal choice for efficient filtration of critical industries.
Feature
Applications
| Filter Media | Polypropylene |
| Length | 5", ", ", 10", 20", 30", 40" |
| Outside Diameter | "(70mm) |
| Filtration Rating | , , , , , 1μm, 2μm, 3μm, 5μm, 10μm, 20μm, 30μm, 40μm, 50μm, 60μm |
| Core | Polypropylene, Stainless Steel |
| Support/Drainage | Polypropylene |
| Gasket/O-ring | Silicone, EPDM, Viton, NBR, Teflon encapsulated Viton |
| End Cap/Cage | Polypropylene |
| End Cap Type | DOE, 222/Flat, 222/Fin, 226/Flat, 226/Fin, 215/Flat, 215/Fin |
Operation Data for Absolute PP Pleated Filter Cartridges
| Maximum Operating Temperature | 80℃(176℉) |
| Max. Differential Pressure | bar at 20℃ (70 psi at 68℉) |
| bar at 50℃ (50 psi at 122℉) | |
| bar at 80℃ (20 psi at 176℉) | |
| Maximum reverse pressure | 40 psid @ 70°F ( bar @ 21°C) |
| Recommended Change Out Differential Pressure | ΔP 35 psi |
| Filtered Hot Water | 80˚C for 30 min |
| Sterilization Temperature Time | 121˚C (250˚F) for 30 minutes, multiple cycles |
Electron Microscopic Photo of Absolute PP Membrane
| 3D Drawing for Absolute PP Pleated Filter Cartridges | ||||
 |
● Ulti-layers pleated, low pressure drop, high capacity of impurities and long service life ● 100% integrity tested, ineer core and outside cage strengthen capacity of high flow pressure ● Thermal welding techniques ensure Absolute PP Pleated Filter Cartridges no side leakage ● Large surface area allow for high flow rate and higher dirt holding capacity than normal depth filters |
|||
|
Installation Example for Absolute PP Pleated Filter Cartridges |
||||
 |
● Manufactured in continuous lengths up to 40 inches ● Easy to install help to save some manpower and time ● Many kinds of end caps fit for standard filter housings ● Wide range of chemical compatibility used in prefiltration fields ● Various gaskets/O-ring material compatible with a variety of fluids ● Special Absolute PP Pleated Filters can be made, such us . inner core |
|||
End Caps of Absolute PP Pleated Filter Cartridges
| APC | Length | Micron Rating | End Cap | Gasket/O-ring | Adders |
|
APC Series Absolute PP Pleated Filter Cartridges |
5 = 5" | = | A = Double Open End (DOE) | S = Silicone | T = Thicker PP Cage |
| = | |||||
| = " | = | B = 222/Flat(SOE) | |||
| = | E = EPDM | ||||
| = " | = | C = 222/Fin(SOE) | |||
| 1 = 1μm | I = Stainless Steel Insert End Cap | ||||
| 10 = 10" | 2 = 2μm | D = 226//Flat(SOE) | N = NBR | ||
| 3 = 3μm | |||||
| 20 = 20" | 5 = 5μm | F = 226/Fin(SOE) | |||
| 10 = 10μm | V = Viton | ||||
| 30 = 30" | 20 = 20μm | G = 215/Flat(SOE) | S = Stainless Steel Core | ||
| 30 = 30μm | |||||
| 40 =40" | 40 = 40μm | H = 215/Fin(SOE) | T = Teflon Encapsulated Viton | ||
| 50 = 50μm | |||||
| 60 = 60μm |
For Example:
APC-20-5-A-S
APC Series Absolute PP Pleated Filter Cartridges - 20" - 5μm - Double Open End (DOE) - Silicone Gasket
